Polo Elevators Glass Door Architectural Series Dumbwaiter: Precision Vertical Transport for Aesthetic Environments
The Polo Elevators Glass Door Dumbwaiter, from the Architectural Series, offers efficient vertical transport for loads up to 150kg across 2-6 floors. Its robust SS 304 construction with toughened glass panels provides both operational visibility and sophisticated aesthetics, making it ideal for high-end residential, hotel, and restaurant applications demanding precise, low-noise material conveyance.
Quick Answer
This dumbwaiter excels in environments requiring visual integration of vertical transport, combining advanced electro-mechanical reliability with a transparent, hygienic SS 304 and safety glass car.
✓Advanced Geared Motor Drive with Soft Start/Stop & Precision Leveling
✓Comprehensive Safety Interlocks, Overload Sensing, and Toughened Glass
✓Corrosion-Resistant SS 304 Car with Durable Steel Guide Rails
Polo Elevators' Glass Door model from the Architectural Series is a premier choice for high-end residential homes and boutique cafes where aesthetic visibility is paramount. With its SS 304 construction and toughened glass panels, it offers a sophisticated look for up to 150kg loads across six floors. You should buy this if you want a stylish, low-noise solution for luxury hospitality or modern homes. However, avoid it for rugged industrial use; the 0.40 m/s speed and glass finish are designed for elegance, not heavy-duty warehouse crates.
✓ Who Should Buy
- •High-end residential property owners seeking aesthetic and functional kitchen/utility lifts
- •Restaurant and hotel operators requiring hygienic, visible, and efficient food/material transport
- •Cafes and commercial establishments where interior design and visual appeal are paramount
✕ Who Should Avoid
- •Industrial facilities requiring heavy-duty material handling exceeding 150kg per trip
- •Installations with severe space constraints that cannot accommodate the 1100mm x 1100mm shaft
- •Applications demanding variable speed control for delicate items (this model has fixed speed)
Product Overview
The Polo Elevators Glass Door Dumbwaiter, a key offering in the Architectural Series (2022-2026), is engineered for sophisticated vertical material transport. Designed to manage loads from 50kg to 150kg, this unit features a durable SS 304 car, complemented by an 8-12mm toughened safety glass viewing panel for enhanced operational visibility and aesthetic integration. Car dimensions are meticulously set at 600mm width, 600mm depth, and 800-1000mm height, allowing for efficient transport of items across 2 to 6 floors, reaching a maximum travel height of 15 meters. The core propulsion is provided by an Electric Traction / Geared Motor drive system, delivering a smooth operational speed of 0.20-0.40 m/s. Power requirements are flexible, accommodating both 230V (Single Phase) and 415V (Three Phase) at 50Hz, with a power rating of 1.0-2.0 kW. Operation is simplified via a Push Button Panel, supported by features such as soft start/stop, precision leveling, and a robust load balancing system. The swing doors, framed in stainless steel and featuring a glass viewing panel, open horizontally for practical access.
| Brand | Polo Elevators |
| Model Name | Glass Door |
| Category | Dumbwaiter |
| Sub Type | Glass Door Dumbwaiter |
| Series | Architectural Series |
| Model Year | 2022-2026 |
| Country Of Origin | India |
| Intended Use | Residential homes, restaurants, cafes, hotels with aesthetic visibility requirement |
Related Products
Engineering Analysis
The Polo Elevators Glass Door Dumbwaiter is fundamentally powered by an Electric Traction / Geared Motor drive system, rated at 1.0-2.0 kW, optimized for its 50-150kg load capacity. This drive mechanism ensures a consistent travel speed of 0.20-0.40 m/s, coupled with soft start/stop functionality to minimize shock to transported goods and mechanical components, thereby extending system longevity. Precision leveling is achieved through sophisticated control algorithms, ensuring accurate floor stops essential for seamless item transfer at each landing. Load distribution is meticulously managed via a counterweight system, which balances the car's weight and a significant portion of the rated load, reducing the required motor power and enhancing energy efficiency. The car's structural integrity is based on SS 304, known for its corrosion resistance, mounted on robust steel guide rails utilizing low noise nylon rollers for smooth, quiet vertical travel. Safety is paramount, integrating a comprehensive interlock system that prevents door opening unless the car is precisely leveled at a floor. An overload sensor immediately halts operation if the 150kg capacity is exceeded, while emergency stop buttons and alarms provide critical user intervention. The 8-12mm toughened safety glass panels on the doors and car offer both visual oversight of items in transit and enhanced occupant safety, conforming to IS 14665 / Indian Elevator Safety Norms. Further protective measures include load overrun protection and temperature overload protection for the motor, ensuring reliable, uninterrupted service within specified operational parameters.
Technical Support & FAQs
Engineering Analysis
The Polo Elevators Glass Door Dumbwaiter is fundamentally powered by an Electric Traction / Geared Motor drive system, rated at 1.0-2.0 kW, optimized for its 50-150kg load capacity. This drive mechanism ensures a consistent travel speed of 0.20-0.40 m/s, coupled with soft start/stop functionality to minimize shock to transported goods and mechanical components, thereby extending system longevity. Precision leveling is achieved through sophisticated control algorithms, ensuring accurate floor stops essential for seamless item transfer at each landing. Load distribution is meticulously managed via a counterweight system, which balances the car's weight and a significant portion of the rated load, reducing the required motor power and enhancing energy efficiency. The car's structural integrity is based on SS 304, known for its corrosion resistance, mounted on robust steel guide rails utilizing low noise nylon rollers for smooth, quiet vertical travel. Safety is paramount, integrating a comprehensive interlock system that prevents door opening unless the car is precisely leveled at a floor. An overload sensor immediately halts operation if the 150kg capacity is exceeded, while emergency stop buttons and alarms provide critical user intervention. The 8-12mm toughened safety glass panels on the doors and car offer both visual oversight of items in transit and enhanced occupant safety, conforming to IS 14665 / Indian Elevator Safety Norms. Further protective measures include load overrun protection and temperature overload protection for the motor, ensuring reliable, uninterrupted service within specified operational parameters.
