ABB 2P 40A 30mA RCBO (DS301C-C40/0.03) – Home

03 is a 40A 2P (1P+N) RCBO designed for 230V residential applications, combining earth leakage and overcurrent protection in one unit.This 30mA Type AC device is installed on 35mm DIN rails to protect final circuits from faults and human contact hazards.

Quick Answer

Absolutely, the ABB DS301C-C40/0.03 RCBO is a crucial upgrade for any Indian home seeking superior electrical safety. It integrates 40A overcurrent and life-saving 30mA earth leakage protection for 230V residential applications. This single unit simplifies wiring while ensuring compliance with IS 12640, making it ideal for new installations or safety upgrades.

✓Superior life safety protection — 30mA sensitivity trips instantaneously to prevent electrocution.
✓6kA breaking capacity and 10kA conditional short circuit rating provide robust protection against heavy faults.
✓Compact 1-module design saves space — 18mm unit width fits easily into crowded residential panels.
✓20,000 cycles mechanical endurance and 10,000 cycles electrical endurance ensure years of reliability.
✓Halogen-free and RoHS compliant construction — UL94 V2 flammability rating minimizes toxic risks during fires.
✓1.5W power loss per pole maintains efficiency while operating within a -25°C to +55°C temperature range.

The ABB DS301C-C40/0.03 RCBO is essential for Indian homeowners, offering combined 40A overcurrent and critical 30mA earth leakage protection for 230V residential circuits. Avoid this model if your application is industrial or requires different current/mA ratings.

Product Overview
The ABB DS301C-C40/0.03 is a 40A 2P (1P+N) RCBO designed for 230V residential applications, combining earth leakage and overcurrent protection in one unit. This 30mA Type AC device is installed on 35mm DIN rails to protect final circuits from faults and human contact hazards. It meets IEC 61009-1 and IS 12640 standards to ensure reliable safety across a wide 180–264V voltage range.

Related Products

Engineering Analysis
The 30mA sensitivity is essential for life safety as it trips @ 1x Idn in ≤300ms, preventing ventricular fibrillation during accidental contact. The 6kA breaking capacity handles high-energy faults at the final circuit level, while the C-curve trip characteristic accommodates typical residential inductive loads. The 2P configuration with a switched neutral ensures total isolation of the faulty circuit, which is vital for modern TN or TT earthing systems.
